Precast concrete detailing
We provide for all facets of detailing and our deliverable can include a range of items listed below.
- Precast shop drawing plans & elevations
- Precast shop drawings for slabs, walls, columns, beams (refer below)
- Lifting & bracing insert locations (certification by others)
- Steel shop drawings for cast-in & erection brackets precast
- Detailing of cast-in services to precast concrete eg. electrical, mechanical, hydraulic
- Starter bar layouts and insitu concrete works coordination
- Project coordination through external online document control systems
- Request for information (RFI) and technical query (TQ) management
- Collection of design information required for shop detailing
- Precast Concrete to steelwork coordination
- Precast quantity take-offs for estimating
Precast shop drawing is also commonly referred to as precast drawings, wall panel detailing, panel detailing, precast panel drawings, fabrication drawings, piece tickets & shop tickets.
Our precast project services can include developments of all sizes. Below of a list of project types we can cover.
- Architectural Precast
- Abutment walls
- Balcony slabs
- Balustrades
- Beams
- Bridge beams
- Bunds
- Civil structures
- Columns
- Crypts
- Culverts (drainage)
- Curved concrete
- Entry statements
- Feature artwork
- Feature bollards
- Grain Silos
- Hollowcore floors
- Hollowcore walls
- Lift cores
- Marine Structures
- Pedestrian Underpass
- Pits
- Planters/Tree wells
- Pre-stressed beams
- Post tensioned beams
- Prison buildings
- Ramps
- Retaining walls
- Sandwhich panels
- Seats
- Shell beams
- Slabs
- Sound/Noise walls
- Stadiums structures
- Stairs
- Steps
- Street furniture
- Structural precast
- Super T/Tee Roff beams
- Tilt-up panels
- Wharf structures
Steel shop detailing
Westdraft does not shop detail steelwork as a core service, however if required, we can provide a combined fee for shop detailing of precast & steel structures through our relationship with steel detailers.
